Turbo Part No.：49173-03410,49173-03430,49173-03400,49173-03420,49173-03440
OE No.:1E038-17015,1A024-17014,1G643-17014,1G643-17015,1G673-17011,1E288-17011
Model：TD025M
Turbo Brand:MHI
Application：Kubota Industrial D1105-T-B-JACOBSEN-2 200
Kubota Agricultural D1503-M-T 2000 Kubota Industrial D1503-M-DI-T-EBB 2000
Kubota Agricultural D1105-T-EBB-ZERO-1 2000
Kubota Industrial D1105-T-E3-STD 2000
Kubota Industrial D1105-E3B-TORO-2 2000
Jack ID:5-00-1052
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
