Turbo Parts No.:40002435, 40001940, 40002436, 40001684, 40005660, 402TN100102
OE No.:851365, 8514266, 8514267, 8511719, 8582021, 8591734, 851171905, 11658513652
Model:BM65
Turbo Brand:BMTS
Car Application:2016- BMW 114, 116, X1 B37D15A,Gasoline;2016- MINI One, Cooper, Clubman, Countryman 1.5D
JACK ID:10-00-1711X
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
