Turbo Parts No.:167380, 171169, 167384, 179578, 173305, 178480
OE No.:113-7919,0R6880, 176-0389,0R9795, 0R6889,0R6881, 106-7407, 219-1911, 10R0921
Turbo Model:S3BSL119,S330W064,S3B
Turbo Brand:SCHWITZER
Car Application:Caterpillar Earth Moving 3306 1994-2002
JACK ID:4-00-1599
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
