Turbo Parts No.:VV21-A6510900486, VV21-A6510900786, VV21-A6510900586, AL0059, AL2011, 9V101
OE No.:A6510900786
Turbo Model:RHF4V
Turbo Brand:IHI
Car Application:Mercedes-Benz C200 CDI / Sprinter 210, 213, 310,410, 413, 510,513 CDI OM651 2009
JACK ID:6-00-1319X
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
