Turbo Parts No.:F01A1804100221, F01A1612070390, F01A1707270157, F02A2008250057
OE No.:28231-4A820,KVAAAF4002,28231-4A870,KVAAAF4004
Turbo Model:RHF4
Turbo Brand:IHI
Car Application:Hyundai H100 Porter II 1.6 TGDI G4FJ 2016；Kia Bongo III 1.6 TGDI G4FJ 2016；Hyundai / Kia Elantra / Soul 1.6 TGDI G4FJ 2016
JACK ID:6-00-1700X
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
