Turbo Parts No.:49335-04220, 49335-04230, 49335-04240
OE No.:M4D3-6K682-ED
Turbo Model:TF035L18
Turbo Brand:MHI
Car Application:LAND ROVER - DISCOVERY SPORT/FREELANDER/EVOQUE/;JAGUAR F-PACE / XF/ XE -DIESEL INGENIUM D200 - 2021- GEOMETRIA
JACK ID:5-00-1761X
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
