Turbo Parts No.:178723, 175971, 177310, 1370-970-0015, 178724, 177334, 178732, 176415, 177306, 1370-970-0033, 178733, 177305, 177168, 176414, 175431, 1370-970-0025, 1370-970-0032, 178734, 177155, 174700, 1370-970-0011, 478723, 1370-980-0015
OE No.:RE529219, RE534537, RE535699, DZ108134, RE535700, RE535704, RE531248, DZ108130, RE535703, RE535695, RE534551, RE525583, DZ108128,DZ108129, RE535702 RE525503, DZ108124, RE534537, SE502429
Turbo Model:S300BV124
Turbo Brand:SCHWITZER
Car Application:John Deere Grader 6090H 2005-2007;John Deere Tractor 8430 6090H 2004-2007
JACK ID:4-00-0996X
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
