Turbo Parts No.:1639-970-0000;1639-970-0003;1639-970-0006;1639-970-0020
OE No.:F1FZ-6K682-D;DS7G-6K682-DB
Turbo Model:B0BG
Turbo Brand:BORGWARNER
Car Application:Volkswagen Passat 1.6 TDI-CR DCXA;Ford C-max II/Focus III/Galaxy III UNCJ, UNCK 1.5LP 2014-2020
JACK ID:J20B0B-158
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
