Turbo Parts No.:5303-970-0433, 5303-970-0443, 5303-970-0477, 5303-970-0478, 5303-970-0543,5303-970-0621
OE No.:04L253124A
Turbo Model:BV43
Turbo Brand:KKK
Car Application:Volkswagen Passenger car 2.0 TDI-CR MDB 2019
JACK ID:2-00-1634AX
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
