Turbo Parts No.:1000-970-0210, 1000-970-0268, 1000-970-0324, 1000-970-0366
OE No.:AL0082, A6540900180, A6540900280, A6540900480, A6540909100
Turbo Model:B03G-R2S (L)
Turbo Brand:BORGWARNER
Car Application:Mercedes-Benz Sprint and Vito 2.0 TD OM654DE20LA 2016-2017
JACK ID:2-00-1074BX
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
