Turbo Parts No.:VL36;VL38
OE No.:55218934;55212916;55222014
Turbo Model:RHF3
Turbo Brand:IHI
Car Application:Fiat 500 Abarth 1.4 2009- Fiat Bravo II 2007-2014/Lancia Delta III 2008-2014/Alfa Romeo Mito 2008-2011
JACK ID:J60HF3-507
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
