Turbo Parts No.:F01A1504070031, F01A1711290228
OE No.:28231-2B800
Turbo Model:RHF4
Turbo Brand:IHI
Car Application:2017-2018 Kia Forte EX, LX, S with 2.0L L4 Engine；2017-2018 Kia Forte5 EX, LX, SX with 1.6L/2.0L L4 Engine；2017-2019 Kia Soul with 1.6L/2.0L L4 Engine；2017-2020 Hyundai Elantra, Sport with 1.6L L4 Engine；2018- Hyundai Elantra GT, Sport with 1.6L L4 Engine；2019-2020 Hyundai Elantra GT, N Line with 1.6L L4 Engine
JACK ID:6-00-1700AX
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
