Turbo Parts No.:3773761, 3791617, 3794997, 4033317, 4041259, 4041261, 4043499, 4045105, 4046958, 4046959, 4046960, 4046961, 5322533, 5503767
OE No.:504269261, 504269260, 504139769, 504182849, 5322533, 5042692600, 5503767, 500061032, 5042692610
Turbo Model:HE531V(CURSOR10)
Turbo Brand:HOLSET VGT
Car Application:Iveco Truck Cursor 10 2005-2007
JACK ID:3-00-1190X
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
