Turbo Parts No.:1000-970-0115;1000-970-0101;1000-970-0051;1000-970-0069
OE No.:03L145715M, 03L145715C, 03L145715H, 03L145873B, 3L145701S
Turbo Model:R2S KP35+K04
Turbo Brand:KKK
Car Application:Volkswagen Amarok 2.0L TDI-CR 2006-13
JACK ID:J20R2S-168
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
