Turbo Parts No.:AL0059, 9V101
OE No.:A6510900486, A6510900586, A6510900786,V30VEY-SR021B
Turbo Model:RHF4
Turbo Brand:IHI
Car Application:Mercedes-Benz A Class / B Class / C Class 1.8/2.0/2.2T OM651.930/OM651.901 2012
JACK ID:6-00-1318AX
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
