Turbo Parts No.:852915-0001, 852915-0002, 852915-0003, 852915-0004, 852915-0005, 852915-0006
OE No.:2371648, 2328180,2371649, 2732025, 2732026, 2840274
Turbo Model:GTC4594BNS
Turbo Brand:GARRETT
Car Application:Scania P, G & R Series Trucks DC13 115 410 12.7L 2013 ；Scania OmniExpress Irizar Bus Caetano DC 13 147 12.7L 2016-2018 ；Scania P, G & R Series Trucks DC13 124 450 12.7L 2013 ；Scania OmniExpress DC 13 147 12.7L 2018
JACK ID:1-00-1514X
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
