Turbo Parts No.:1855-970-0017, 1855-970-0021, 1855-970-0031, 1855-970-0036, 1855-970-0037
OE No.:07K145701H, 07K145701J, 07K145701L, 07K145701M, 07K145701N
Turbo Model:B03G
Turbo Brand:BORGWARNER
Car Application:Audi TT RS 2.5 TFSI (8S) DAZA R5 Gasoline 2015-2019
JACK ID:2-00-1177X
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
