Turbo Parts No.:49389-03000, 49389-03001, 49389-03002, 49389-03010, 49389-03011, 49389-03012, 49389-03020, 49389-03021, 49389-03022, 49389-03030, 49389-03031, 49389-03032, 49389-03040, 49389-03041, 49389-03042
OE No.:1J501-17012,1J501-17013,1J501-17014
Turbo Model:TD04HL4
Turbo Brand:MHI
Car Application:Kubota Industrial, Tractor V3800-CR-TIE4-BB, V3800-CR-TIE4-U
JACK ID:5-00-0011
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
