Turbo Parts No.:466154-0014, 466154-0015, 466154-0016, 466154-0017, 466154-0020, 466154-0031, 466154-0032, 466154-0040
OE No.:30967399, 40961599, 40961799, 40963299, 4760967499
Turbo Model:TA5127-2
Turbo Brand:GARRETT
Car Application:Mercedes-Benz MBB. BRAZIL OM447LA ;Mercedes-Benz IND.ENG. OM447LA ;Mercedes-Benz AIRPRT TRACTOR OM447HLA ;Mercedes-Benz 1935/1941 OM447LA ;Mercedes-Benz Truck OM447LA
JACK ID:1-00-1419A
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
